Voltage / Frequency / Phase: 230v/50hz/Single Phase
Cooling Capacity: 5150 W
Power Input: 1840 W
Electricity Consumption ( 1600 Hours ) Per Year: 1128.49 Units
Running Current (AMPS): 8.4
Air Flow Volume (Dry Cfm) (High ): 471 CFM
Noise Level Indoor (High/ Medium / Low) In Db(A): 52/45/42
Dimension (W X H X D ) mm: 910 x 294 x 206
Net Weight IDU (Kg): 9
Noise Level Outdoor In Db(A): 45/40/32
10 Years Compressor Warranty
Refrigerant: R32
Anti-Corrosive Coating On Condenser & Evaporator
Twin Rotary Inverter Compressor
R32 - Low Global Warming Refrigerant
Active Carbon Filter
100% Copper Condenser And Connecting Pipe
Get Quotation
Enquiry Now
Services That We Offer
Specification
Additional Information
Model No.
GIC 18 WTC 3 WSB
Color
White
Capacity (Watts)
5150
Energy Efficiency (ISEER)
3.53
Moisture Removal (L/hr)
-
Noise Level (Indoor High/Low)
45/40/32
Compressor Type
Twin Rotary
Power Consumption
1128.49 Units Per Year
Voltage
230V/50Hz/single phase
Auto Restart
Yes with Memory Function
On Timer
Yes
Off Timer
Yes
Dehumidification
-
Sleep
Yes
Swing
Horizontal & Vertical Louver / Vertical Swing
Remote Control
LCD with Backlight
Indicators
-
Indoor Unit Size (W x D x H) cm
91 x 20.6 x 29.4
Outdoor Unit Size (W x D x H) cm
76 x 25.6 x 55.2
Indoor Unit Weight (Kg)
9
Outdoor Unit Weight (Kg)
28
Warranty
10 Years Compressor Warranty
Other Features
Modes: Cool/Auto/Dry/Sleep/Eco
Turbo Cooling
Sleep Mode
Timer
Horizontal & Vertical Louver / Vertical Swing
Auto Restart With Memory Function
Fan Speed: Low/Mid/High/Auto/Silent
Blow / Anti Fungal / Self Clean
Anti Freeze Thermostat & Anti-Freezing Protection Function
Self Diagnosis
Hidden Display In IDU
Filter Configuration: Active Carbon, catechin filter
Hydrophilic Blue Fins Evaporator Fins
Copper Condenser With Anti Corrosive Blue Fins
Expansion Device In ODU: Capillary
LCD with Backlight
Night Glow Function On Remote Buttons: No
Compressor
Compressor Type: Twin Rotary
Acoustic Jacket On Compressor: Yes
Refrigerant & Ambient Operations
Refrigerant: R32
Max Ambient Temp (Cooling): 50
Tube Size & Piping Capability
Suction Tube Size Outer Diameter Inch ( mm): 12.7
Liquid Tube Size Outer Diameter Inch ( mm): 6.35
Max Piping Capability Total (M): 15
Max Piping Capability Vertical (M): 5
Refrigerant Additional Charge Beyond 4m (G/M): 15
Installation Kit
Copper Pipe (M): 3
Inter Connecting Cable (M): 3.5
